Before you look at a single wheel design, you need one number: your bolt pattern. Get it wrong and the wheel simply will not go on.
What a bolt pattern means
A bolt pattern such as 6x139.7 has two parts: the number of lug studs (6) and the diameter of the circle they sit on, in millimetres (139.7). You will also see it in inches — 6x139.7 is the same as 6x5.5.
How to find yours
- Check your owner's manual or the specs for your exact year, make and model.
- Count the lug nuts, then measure centre-to-centre across the circle (easy on even numbers: measure straight across between opposite studs).
- Or call us with the year, make and model and we will tell you.
Common patterns for the trucks we see most
| Truck | Bolt pattern |
|---|---|
| Ford F-150 (2004 onward) | 6x135 |
| Chevy Silverado 1500 / GMC Sierra 1500 | 6x139.7 |
| RAM 1500 (2019 onward, new body) | 6x139.7 |
| RAM 1500 (2012–2018) and 1500 Classic | 5x139.7 |
| Toyota Tacoma (2005 onward) | 6x139.7 |
| Toyota Tundra (2007–2021) | 5x150 |
| Toyota Tundra (2022 onward) | 6x139.7 |
| RAM 2500 / 3500 | 8x165.1 |
Bolt pattern is not the whole story. Offset, centre bore and brake clearance matter too — which is why we check the full fitment before a wheel is ordered, and why many aftermarket wheels need hub-centric rings.
Our wheels, by bolt pattern
| Bolt pattern | Wheels |
|---|---|
| 5 x 100 | SST 1 |
| 5 x 108 | SST 1 |
| 5 x 112 | SST 1, Imperial Street Series 2, Imperial Street Series 3, Outlaw Off-Road Series 2 |
| 5 x 114.3 | SST 1, Imperial Street Series 2, Imperial Street Series 3 |
| 5 x 115 | Imperial Street Series 1, Imperial Street Series 2, Imperial Street Series 3 |
| 5 x 120 | SST 1, Imperial Street Series 2, Imperial Street Series 3 |
| 6 x 135 | Imperial Street Series 4, Outlaw Off-Road Rugged 1 |
| 6 x 139.7 | Imperial Street Series 4, Outlaw Off-Road Series 2 |
Wheels are ordered in for you. Mounting and balancing is $100 a set of four, and new wheels usually need TPMS sensors.
Quick answers
What does a bolt pattern like 6x139.7 mean?
Six lug studs on a circle 139.7 mm across. The same pattern is written 6x5.5 in inches.
What is the bolt pattern of a Ford F-150?
6x135 for F-150s from 2004 onward.
Is bolt pattern the only thing that matters for fitment?
No. Offset, centre bore and brake clearance matter too. We check the full fitment before any wheel is ordered.
